BenQ Board (กระดานอัจฉริยะ) Master RM05 Arm Cortex-A78×2+A55×6/8GB/128GB/Arm Mali-G57 MC2/Android 15 (EDLA)

Name: BenQ Board (กระดานอัจฉริยะ) Master RM05 Arm Cortex-A78×2+A55×6/8GB/128GB/Arm Mali-G57 MC2/Android 15 (EDLA) - NEXTPLAY
Price: 82900 THB
Availability: InStock

Price range: 82,900 ฿ through 136,000 ฿ Including VAT 7%

กระดานอัจฉริยะ Master RM05
สัมผัสเทคโนโลยีการศึกษาที่ตรงตามความต้องการ ใช้งานง่าย ปลอดภัย ออกแบบมาเพื่อครูและเจ้าหน้าที่ไอที

รุ่น

Clear

ติดต่อสอบถามข้อมูลเพิ่มเติมได้ที่

เบอร์โทร. 02-491-4564 ext. 1096, 087-984-2890

Line ID: @nextplay

สอบถามผ่าน LINE

ขอใบเสนอราคา

SKU: ไม่ระบุ Categories: Projector, All product, Projector, จอภาพ Tag: Ben Q Interactive Board

ข้อมูลเพิ่มเติม
คุณสมบัติสินค้า

Weight	ไม่ระบุ
Dimensions	ไม่ระบุ

คุณสมบัติสินค้า

Model	RP6505	RP7505	RP8605
Display
Screen size	65’’	75’’	86’’
Panel type	IPS	IPS	IPS
Resolution	4K UHD 3840 × 2160 pixels	4K UHD 3840 × 2160 pixels	4K UHD 3840 × 2160 pixels
Active area	56.2 × 31.6 inch (1428.5 × 803.5 mm)	64.9 × 36.5 inch (1650.2 × 928.2 mm)	74.4 × 42.0 inch (1895.0 × 1066.0 mm)
Aspect ratio	16:9	16:9	16:9
Panel brightness (typical)	450 nits	450 nits	450 nits
Color depth	10-bit	10-bit	10-bit
Color gamut	72% NTSC	72% NTSC	72% NTSC
Contrast ratio (typical)	1500:1	1500:1	1200:1
Dynamic contrast ratio	50,000:1	50,000:1	50,000:1
Response time	8 ms	8 ms	8 ms
Flicker-free	Yes	Yes	Yes
Low blue light	Eyesafe 3.0	Eyesafe 3.0	Eyesafe 3.0
Anti-glare	Yes	Yes	Yes
Germ-resistant technology	Nano-ionic silver	Nano-ionic silver	Nano-ionic silver
Hardness	9H tempered	9H tempered	9H tempered
Backlight life (typical)	50,000 hrs	50,000 hrs	50,000 hrs
Touch technology
Touch points	Up to 50	Up to 50	Up to 50
Touch response time	< 2.5 ms	< 2.5 ms	< 2.5 ms
Touch technology	Ultra Precision IR	Ultra Precision IR	Ultra Precision IR

System
CPU	Arm Cortex-A78 × 2 + A55 × 6	Arm Cortex-A78 × 2 + A55 × 6	Arm Cortex-A78 × 2 + A55 × 6
NPU	10 TOPS	10 TOPS	10 TOPS
GPU	Arm Mali-G57 MC2	Arm Mali-G57 MC2	Arm Mali-G57 MC2
Memory \| Storage	16 GB I 256 GB	16 GB I 256 GB	16 GB I 256 GB
Operating system	Android 15 (EDLA)	Android 15 (EDLA)	Android 15 (EDLA)
Connectivity
USB-C	1 × USB 3.0 (full-featured PD 100W) \| 1 × USB 2.0	1 × USB 3.0 (full-featured PD 100W) \| 1 × USB 2.0	1 × USB 3.0 (full-featured PD 100W) \| 1 × USB 2.0
USB-C out	1 × USB 2.0 (data, video out, audio out, touch)	1 × USB 2.0 (data, video out, audio out, touch)	1 × USB 2.0 (data, video out, audio out, touch)
USB-A	4 × USB 3.0 \| 3 × USB 2.0	4 × USB 3.0 \| 3 × USB 2.0	4 × USB 3.0 \| 3 × USB 2.0
USB-B (touch)	3 × USB 3.0	3 × USB 3.0	3 × USB 3.0
HDMI (in \| out)	3 × HDMI 2.0 \| 1 × HDMI 2.0	3 × HDMI 2.0 \| 1 × HDMI 2.0	3 × HDMI 2.0 \| 1 × HDMI 2.0
DisplayPort	1 × DisplayPort 1.2a	1 × DisplayPort 1.2a	1 × DisplayPort 1.2a
VGA	1	1	1
Audio in	1 × 3.5 mm microphone jack 1 × 3.5 mm audio jack (VGA)	1 × 3.5 mm microphone jack 1 × 3.5 mm audio jack (VGA)	1 × 3.5 mm microphone jack 1 × 3.5 mm audio jack (VGA)
Audio out	1 × earphone jack	1 × earphone jack	1 × earphone jack
S/PDIF out	1 (optical)	1 (optical)	1 (optical)
Ethernet	2 × Gigabit (Android)	2 × Gigabit (Android)	2 × Gigabit (Android)
Wi-Fi	Wi-Fi 6	Wi-Fi 6	Wi-Fi 6
Bluetooth®	Bluetooth 5.2	Bluetooth 5.2	Bluetooth 5.2
OPS slot (for slot-in PC)	1	1	1
microSD reader	1	1	1
RS-232	1	1	1

Built-in peripherals
Soundbar	70W (2 × 25W speakers \| 1 × 20W subwoofer)	70W (2 × 25W speakers \| 1 × 20W subwoofer)	70W (2 × 25W speakers \| 1 × 20W subwoofer)
Microphone	8-microphone array (up to 39 ft \| 12 m)	8-microphone array (range: up to 39 ft \| 12 m)	8-microphone array (range: up to 39 ft \| 12 m)
NFC sensor	Yes	Yes	Yes
Air ionizer	Yes	Yes	Yes
Air quality sensor	CO2, PM2.5, PM10, TVOC, CH2O, temperature, humidity	CO2, PM2.5, PM10, TVOC, CH2O, temperature, humidity	CO2, PM2.5, PM10, TVOC, CH2O, temperature, humidity
Ambient light sensor	Yes	Yes	Yes
IR sensor	Yes	Yes	Yes
Software
Whiteboarding	EZWrite 6	EZWrite 6	EZWrite 6
Wireless screen sharing	InstaShare 2	InstaShare 2	InstaShare 2
Account management	AMS	AMS	AMS
Device management	DMS	DMS	DMS
Broadcast system	X-Sign Broadcast	X-Sign Broadcast	X-Sign Broadcast
Quick access tool	Floating Tool	Floating Tool	Floating Tool
Power
ENERGY STAR®	Yes	Yes	Yes
Power	AC 100-240V 50/60 Hz	AC 100-240V 50/60 Hz	AC 100-240V 50/60 Hz
Standby power consumption	< 0.5W	< 0.5W	< 0.5W
Typical power consumption	77.4W	91.1W	126.4W
Accessories
Cables	1 × HDMI (9.8 ft \| 3 m), 1 × USB-B touch (9.8 ft \| 3 m), 1 × USB-C (4.9 ft \| 1.5 m)	1 × HDMI (9.8 ft \| 3 m), 1 × USB-B touch (9.8 ft \| 3 m), 1 × USB-C (4.9 ft \| 1.5 m)	1 × HDMI (9.8 ft \| 3 m), 1 × USB-B touch (9.8 ft \| 3 m), 1 × USB-C (4.9 ft \| 1.5 m)
Wall mount	Preinstalled	Preinstalled	Preinstalled
Pens	2	2	2
Remote control	1	1	1

Physical
Dimensions (W × H × D)	58.6 × 36.9 × 5.1 inch (1488.4 × 937.3 × 130.0 mm)	67.3 × 41.8 × 5.1 inch (1709.4 × 1060.8 × 130.0 mm)	77.0 × 47.3 × 5.1 inch (1957.0 × 1200.6 × 130.0 mm)
Shipping dimensions (W × H × D)	64.1 × 40.3 × 8.2 inch (1628.0 × 1024.0 × 208.0 mm)	73.3 × 46.1 × 8.1 inch (1863.0 × 1170.0 × 205.0 mm)	83.1 × 51.7 × 8.1 inch (2110.0 × 1314.0 × 205.0 mm)
Weight (product I shipping)	76.1 lbs \| 98.1 lbs (34.5 kg \| 44.5 kg)	99.4 lbs \| 128.3 lbs (45.1 kg \| 58.2 kg)	121.3 lbs \| 162.3 lbs (55 kg \| 73.6 kg)
Mount interface \| Screws	VESA 600 × 400 mm \| 4 × M8 × 25L	VESA 800 × 400 mm \| 4 × M8 × 25L	VESA 800 × 600 mm \| 4 × M8 × 25L
Pen tray	Yes	Yes	Yes
Environment
Operating humidity	10% – 90% RH non-condensing	10% – 90% RH non-condensing	10% – 90% RH non-condensing
Operating temperature	32°F – 104°F \| 0°C – 40°C	32°F – 104°F \| 0°C – 40°C	32°F – 104°F \| 0°C – 40°C
Storage humidity	10% – 90% RH non-condensing	10% – 90% RH non-condensing	10% – 90% RH non-condensing
Storage temperature	-4°F – 140°F \| -20°C – 60°C	-4°F – 140°F \| -20°C – 60°C	-4°F – 140°F \| -20°C – 60°C
